Hoffman Amplifiers Parts List Page for Relay_Power_Supply_Board

Watch this Shopping cart tips video

File Name = Relay_Power_Supply_Board

File Date = 11/05/2011

File Notes = All the parts to populate the Relay power Supply Board

Discontinued items will be at the bottom of the parts list
Go here for information about Out of Stock Items and Discontinued items

Item Id
Page link		 Description QTY 1 2 3 Each Ext
BoardRelay1 Relay Power Supply Board - ZD3 - $3.00 $3.00
Bridge2 1000v - 3 amp bridge - ZD2 - $1.17 $1.17
7805 5 Volt Regulator - ZD1 - $0.85 $0.85
4700/16v 4700uf/16v Radial - EA6 - $1.57 $1.57
Lug2 Short Turret Lugs for .062 inch board - ZF0 - $0.25 $1.00
Screw6/32x5/8 6/32 x 5/8 Phillips Screw - ZG1 - $0.14 $0.28
Nut Keps 6/32 6/32 Keps Nut - ZG2 - $0.17 $0.34
StandoffNylon2 1/4 inch nylon #6 hole - ZF5 - $0.42 $0.84
Parts total $9.05
